Cloud Monitoring Module Wireless Network Communication Protocol

Cloud Monitoring Communication Module Genset Generator Parameter Adjust Function

• CMM366A-WIFI Cloud Monitoring Communication Module is WIFI wireless network communication protocol switch module which can achieve genset (with SCI) connect to Internet. After logging into cloud server, module will receive corresponding genset controller communication protocol from cloud server.
• And module gains genset data via RS485 port, USB port, LINK port or RS232 port then send the data to corresponding cloud server through WIFI wireless network for achieving user’s real-time monitoring to running status and searching of running records via APP (IOS or Android) and PC terminal devices.

Features:

• Take JSON network data communication protocol, upload real-time data variation and take compression algorithm to vastly reduce network flow at the same time
• Users can upload monitoring data to the server for analyzing based on the user-defined “history data upload interval”
• When alarm occurs it can upload data to server immediately
• 2 auxiliary digital input ports which can receive external alarm signal
• 1 auxiliary relay output ports which can output various of alarm signal
• Perpetual calendar and clock functions
• Power and multiple communication status indicators on front panel that working status is clear at a glance
• Lamp test function
• Parameter adjust function: users can adjust parameters via USB port
• Take standard π-type 35mm guide-rail installation or screw-fixed installation that the module can be installed in the genset control box

• WIFI/Ethernet/3G/2G:WIFI
• Digital Input:2
• Relay Output:1
• RS485:Y
• RS232:Y
• LINK:Y
• USB Device:Y
• USB Host:Y
• Clock:Y
• Installation Method:Railway/screw fixing
• DC Supply:DC(8～35)V
• Case Dimensions(mm):73*105*35
• Operating Temp.:(-25～+70)℃
• Net Weight(kg):0.15
